Eleaf BASAL User Manual


How to Use
Power on/off: press the fire button 5 times in quick succession to turn on/off the device. Keep holding the fire button to take a puff when the device is powered on. Please adjust the wattage to a proper range according to your atomizer before use.

Adjust wattage: when the device is powered on, the output wattage can be adjusted from 1W to 30W by pressing up button or down button, up button to increase and down button to decrease. Long press up button or down button can rapidly increase or decrease the wattage level.

Stealth on/off: press the fire button and down button simultaneously when the device is powered on to switch between Stealth On and Stealth Off mode. In Stealth On mode, you can vape with the screen off and you can press the fire button once to see current setting.

Adjustment buttons lock/unlock: keep pressing up button and down button simultaneously for two seconds when the device is powered on, then the up and down buttons will be locked and the screen will display “Lock”. In the same way, the up and down buttons can be unlocked and the screen will display “Unlock”. Through this operation, you can protect the buttons from unintentional presses and prolong their lifespan.

Turn display upside down: keep pressing up button and down button simultaneously for two seconds when the device is powered off, the screen display will rotate 180 degrees. You can view the screen from two different angles through this operation.

Switch display interfaces: in power-on state, keep holding up and fire buttons till the interface flashes; when it’s flashing, press up or down button to choose one parameter to be displayed on main interface among voltage (V), puff (P), total vaping seconds (S) and a longer battery bar; finally press fire button once to confirm your choice.

Charging: the device can be charged through USB port at the bottom of the device via wall adapter or a computer.

Properties Atomizer Protection: each time when vaping time exceeds 10 seconds, the output shuts off automatically with “Over 10s” displayed on the screen.

Atomizer Short Alert: if the resistance of coil is lower than 0.6ohm, the screen will display “Atomizer Short” when you press the fire button to vape.

No Atomizer Alert: the screen will display “No Atomizer” when there is no atomizer connected or when the resistance of the coil you use is larger than 3.0ohm.

Low-voltage Protection: when the voltage of the device is below 3.3V, the screen will display “Lock” and the output will cut off automatically. Charge the device to reactivate it.

Temperature Alert: if the temperature of device is over alert temperature, the output will shut off automatically and the screen will display “Device Too Hot”. You can continue to vape after it cools down.

Warnings
1. Please keep out of reach of children.
2. This product is not recommended for use by young people, non-smokers, pregnant or breast-feeding women, or persons who are allergic/sensitive to nicotine.

Contra-indication
1. Do not attempt to repair the product by yourself as damage or personal injury may occur.
2. Do not leave the product in high temperature or damp conditions, otherwise it may be damaged.
3. Do not use this product for other purposes except only for vaping and don’t swallow the e-liquid.

Possible Adverse Effects
1. This product may be hazardous to health and contains nicotine which is addictive.
2. For people with adverse reaction after using this product, it is recommended to use the e-liquid with lower nicotine content or no nicotine.
